DynoMAX Super Turbo Performance Exhaust Systems for Ford Trucks

Super Turbo
Exhaust Kits

New

SUPER TURBO EXHAUST KITS FOR FORD TRUCKS

BRONCO - FULL SIZE Ford Bronco

Year

Cyls.

MODEL & ENGINE

System #

1987-93

6

Bronco w/4.9L (300)

17410

1992-95

8

Bronco w/5.8L (351)

17389

1987-96

8

Bronco w/5.0L (302)

17410

EXCURSION - 2WD/4WD

Year

Cyls.

MODEL & ENGINE

System #

2000

8

Excursion W/ 6.8L, 137.1" WB, Exits on Passenger Side, 3" Single Inlet / 3" Single Tail Pipe Stainless Steel Spout

19328

EXPLORER / MOUNTAINEER - 2WD / 4WD

Year

Cyls.

MODEL & ENGINE

System #

1990-92

6

Explorer w/4.0L (2DR.)

17438

1990-92

6

Explorer w/4.0L (4DR.)

17430

1993-94

6

Explorer w/4.0L (2DR.)

17416

1993-94

6

Explorer w/4.0L (4DR.)

17415

1995-96

6

Explorer/Mountaineer w/4.0L SOHC
(4DR.) 2 1/4" Single Inlet/ 2 1/4" Single Tail Pipe w/ T304 Stainless Steel Tip

17377

1996-00

6

Explorer/Mountaineer w/4.0L (4DR.) 2 1/4" Single Inlet/ 2 1/4" Single Tail Pipe
w/ T304 Stainless Steel Tip

17346

1996-4/98 8 Explorer/Mountaineer w/5.0L (4DR.)
2 1/2" Single Inlet/ 2 1/4" Single Tail Pipe
w/ T304 Stainless Steel Tip 17352

1998-00 8 Explorer/Mountaineer w/5.0L (4DR.)
Dual Inlet Muffler / 2 1/2" Single Tail Pipe
w/ T304 Stainless Steel Tip 19316



F SERIES - 2 & 4 WD

Year

Cyls.

MODEL & ENGINE

System #

1997

6,8

F150/250 w/4.2L,4.6L,5.4L,120",138",157" WB 2 1/2" Single Inlet/ 3" Side Exit Tail Pipe w/ Stainless Spout

17367

1998-00 6 F150/250 w/4.2L,157" WB
3" Single Inlet / 3" Full Single Tail Pipe
w/ T304 Stainless Steel Spout 17115

1998-00 8 F150/250 w/4.6L,120" WB
3" Single Inlet / 3" Full Single Tail Pipe
w/ T304 Stainless Steel Spout 17339

1998-00 6,8 F150/250 w/4.2L,4.6L,5.4L,138" WB
3" Single Inlet / 3" Full Single Tail Pipe
w/ T304 Stainless Steel Spout     17338

1998-00 8 F150/250 w/4.6L,5.4L,157" WB
3" Single Inlet / 3" Full Single Tail Pipe
w/ T304 Stainless Steel Spout     17115

F SERIES - 2WD / 4WD

Year

Cyls.

MODEL & ENGINE

System #

1987-96

6

F150/250 w/4.9L,116",133",138" WB

17447

1987-96

8

F150/250 w/5.0L,116", 133", 138" WB

17447

1984-96

8

F150/250 w/5.8L,116", 133", 138" WB
w/Dual Tail Pipes (Exc. Flairside)
(Under 8500 GVW)

17447

1988-96

8

F250 HD w/5.8L, 7.5L 133",155"WB
w/converter (over 8500GVW) (after 2/88)
(Exc. 93-96 w/7.5L)

17407

1988-96

8

F350 w/5.8L, 7.5L 133"WB
(after 2/88)(Exc. 93-96 w/7.5L)

17407

1988-92

8

F350 w/5.8L, 7.5L 155"WB
(2 WD only) (after 2/88)

17407

1988-96

8

F350 w/5.8L, 7.5L 168"WB
(after 2/88)(Exc. 93-96 w/7.5L)

17407

F SERIES - 2WD / 4WD
CAT- BACK DUAL KITS - TAIL PIPES EXIT ON EACH SIDE OF TRUCK

Year

Cyls.

MODEL & ENGINE

System#

1987-96

6

F150 w/4.9L 116"WB Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17305

1987-96

6

F150/F250 w/4.9L 133" & 138" WB (Under 8500 GVW)
Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17312

1987-96

8

F150 w/5.0L & 5.8L 116"WB Exits Rear on Either Side of License Plate 3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17305

1987-96

8

F150/F250 w/5.0L & 5.8L 133" & 138" WB (Under 8500 GVW)
Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17312

1997-00

6

F150/250 w/4.2L,120",133",138",157" WB (Under 8800 GVW)
Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17321

1997-00

8

F150/250 w/4.6L,5.4L, 120",133",138",157" WB
(Under 8500 GVW) Exits Rear on Either Side of
License Plate 3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17321

1999-00

8

F250/350 Super Duty w/5.4L 137",142",158" WB
Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17313

1999-00

10

F250/350 Super Duty w/6.8L 137",142",158" WB
Exits Rear on Either Side of License Plate
3" Single Inlet Muffler / 2 1/2" Dual Tail Pipes

17313

RANGER / SPLASH



Year

Cyls.

MODEL & ENGINE

System #

1998-00 4,6 Ranger w/2.5L, 3.0L, 4.0L, 112" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe
Tail Pipe has T304 Stainless Steel Tip 17317

1998-00 4,6 Ranger w/2.5L, 3.0L, 4.0L, 118" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe
Tail Pipe has T304 Stainless Steel Tip 17316

1998-00 4,6 Ranger w/2.5L, 3.0L, 4.0L, 126" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe
Tail Pipe has T304 Stainless Steel Tip 17315

1995-97 4,6 Ranger w/2.3L, 3.0L, 4.0L, 108" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe 17320

1995-97 4,6 Ranger w/2.3L, 3.0L, 4.0L, 114" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe 17319

1995-97 4,6 Ranger w/2.3L, 3.0L, 4.0L, 125" WB
2 1/4" Single Inlet / 2 1/4" Tail Pipe 17318

1993-94

6

Ranger / Splash w/3.0L, 4.0L
Due to Multiple Wheel Bases
Muffler Inlet Pipe required to complete
installation. Not included in kit.

17402

1982-92

4,6

Ranger w/All Engines, Includes Diesel
Due to Multiple Wheel Bases
Muffler Inlet Pipe required to complete
installation. Not included in kit.

17464
